Dana Crystal Models - tetragonal

by ntdesign

This is a reproduction of "The Dana Set of Wooden Crystal Models" originally produced by Dr. Krantz Rheinisches Mineralien-Kontor (Bonn). triclinic monoclinic orthorhombic hexagonal/trigonal tetragonal cubic I recreated the models based on reference images in "Dana's Textbook of Mineralogy" ( https://archive.org/details/DanasTextbookOfMineralogy ), with forms taken from the catalogue available here (provided by the company): https://mineralogy.eu/models/Krantz/Krantz_31_3.pdf Whenever a model corresponds to a crystal structure, the known unit cell constants were used. In all other cases I approximated to match the pictures in Dana's book. Please note that I do not have an original set to compare, so there might be small differences. Also the scaling is arbitrary and probably totally different. There's a labelled (by catalogue number) and unlabelled version. I also include the OpenScad file I used for embossing, in case somebody wants to adjust the labels. Changes I made to correct apparent errors in the catalogue (to match Dana's book): No. 64: {120} added (missing in catalogue) No. 87: {11-1} removed (not in the book/picture) No. 94: {135} changed to {153} to match picture No. 95: face not in catalogue, used {121} to match picture Big Thanks to Prof. Gervais Chapuis for making me aware of this set's existence and sending me his catalogue! Print Settings Printer: Biqu B1 Supports:  Yes Resolution: 0.2mm Infill:  10% Filament: 3DJake PLA dark green   Notes:   Some of the models require supports. Models are pre-oriented for best print quality.     Category: Learning
