My Wiccan Secret Box

by oasisk

Upload: August 07, 2024 3D creation: on tinkercad.com Source: The Alchemist's Cube: https://www.thingiverse.com/thing:6413185 I was inspired by this superb Alchemist's cube created by CubeNever0dd0reveN to make my own secret cube. It's an 80 x 80 x 80 mm box whose opening is secured by a 4-symbol code. Each of the 4 sides of this box contains a spinning disc with 8 Wiccan symbols. This gives you a wide choice of combinations! Without knowledge of the 4-symbol code you've chosen, it will be impossible to open the box, except by breaking it! The inner dimensions of the container are: 57 x 57 x h76 mm . Printing 9 elements are to be printed: - Disc: 4x - Axis: 4x (+ support) - Dowel: 4x - Plug: 4x - Decor: 5x - Box: 1x - Container: 1x - Upside star: 1x - Downside star: 1x The montage (see photos) - 1 Glue the 4 dowels into the Container holes, with the nipple protruding outwards. - Check that each Pin penetrates all the way into each Disc (if it's too hard, immerse them in very hot water). - 2 Place an Axis inside the box in a free hole, its groove pointing straight TOWARDS THE OPEN SIDE of the box. Fit a Disc at the end of the Axis, with the code symbol pointing straight TO THE BOTTOM of the can (opposite the groove). As the assembly is very tight, gluing is superfluous. Do the same for the other 3 discs. The secret cube is now up and running. - 3 Glue the finishing touches. - - To see all my creations on cults3d, simply click on my name.
