HolyStone HS720 & HS720E battery Charging Block (Wall or Desk Mount)

by sirhc

This design was inspired by the only other charge block I could find here on Thingiverse. It is not remixed from the original but totaly designed from scratch in 123D This is a little block (desk or wall mounted if required) to hold the HolyStone Battery Charger and provide an easy way to insert & remove the battery packs from the well devised Original HolyStone Charger. It requies that the battery charging port doors be removed from the original Charger port. It "should" be as easy as removing the metal pin that holds them in place. (check the how I designed this for pictures giving you an idea how to remove the door flaps/covers) Printing material and speeds are up to you, Here are the settings I used for printing in Petg :- 2 shells / walls 15% infill Supports are required and are minimal to save printing time & plastic. Part orientation for printing is suggested as verticle to the build plate to save on support material. ** NOTE ** Not every printer is calibrated for precision printing and not every plastic prints equall, I have tried to allow for this during design, but as with all things 3d printed You may have to scale the part slightly to get a good fit. ** NOTE ** There are 2 files uploaded. (desk version will lay flat on the desk and support both charging port and batterys) CBds-Battery Charging Desk Block rev4.stl (Wall Mountable version that will attach via screws to support both charging port and batterys) CBds-Battery Charging Wall Block rev4.stl This is still in test print and things may change before a final version is updated ...
