50% keyboard

by ayrtont95

this is a handwired keyboard i have designed its a 50 or 51 key design depending on if you want the volume knob or not, both models are included as well as a fusion file so you can modify to your needs. the picture i have taken is of my test version that is 3d printed. i am using holy panda switches. you will need 2x 2u plate mount stabilizers 51x in4148 diodes 6x M2xL3x3.2od brass threaded inserts 6x m2x10mm screws it has been designed to hold either a arduino pro micro or nano with a usbc port. should also work with an rp2040 zero, it may work with other micro controllers but i dont have them on had to check. i have used hot glue to hold the controller in place, i may update the design to secure it better in the future.
